SMD Resistor

• Application
• Consumer electronics, automotive, power supplies, mobile devices

• Color
• Black (Ferrite bead with standard SMD marking)

• Components
• Ferrite ceramic, internal electrode

• Current Rating
• Varies, typically 100mA - 6A (based on part selection)

• Dimension (L*W*H)
• e.g. 1.0 x 0.5 x 0.5 mm (varies by form factor)

• Features
• Low impedance at DC, effective EMI/RFI suppression, compact SMD package

• Frequency
• Effective for high frequency noise filtering (RF range: MHz-GHz)

• Function
• Noise filtering, EMI suppression

• IP Rating
• Not Rated (not for direct environmental exposure)

• Input
• Signal lines or power supply lines

• Interface
• Surface Mount (SMD)

• Operating Temperature
• -55C to +125C (typical, depends on part)

• Output
• Filtered signal

• Power Source
• Not required (passive component)

• Power Supply
• Not Applicable (Passive Component)

• Product Type
• SMD Ferrite Bead

• Rated Voltage
• 50V

• Response Time
• Instantaneous passive filter

• Size
• Standard SMD sizes (e.g. 0402, 0603, 0805, 1206)

• Supply Voltage
• Up to Rated Voltage (e.g. 50V)

• Thermal Conductivity
• Standard for ferrite materials

• Thickness
• Varies by package (e.g. 0.85mm, 1.0mm)

• Usage
• Surface Mount applications, electronic circuit filtering

• Weight
• ~0.01g (per piece, varies by size)

• Application
• Industrial

• Color
• As Per Availability

• Function
• Electrical

• Power Supply
• electric

• Size
• Different Available

• Usage
• Commercial

• Warranty
• 1 Year
